MD 30/500-850 SLIM (126167) - LED Drivers

back to LED Drivers

126167 - MD 30/500-850 SLIM

MD 30/500-850 SLIM - 126167 - TCI

Features

Rated Voltage
220...240 V
Dimming:
PHASE CUT / IGBT - TRIAC
Additional technical features:
RIPPLE FREE
ACTIVE PFC (pf>0.9)
SELV <>
DIMMING: AMPLITUDE (AM) IEEE1789-2015 - Dim-to-Warm
Suitable for AUTOMATIC WIRING MACHINE
Approvals:
ENEC
CCC
CE
Plastic case:
Slim
Size:
210 x 21 x 30 mm
last update:
5/25/2026
Constant Current
Current
500 mA
220-240 V = Output power
20 W
Current
550 mA
220-240 V = Output power
22 W
Current
600 mA
220-240 V = Output power
24 W
Current
650 mA
220-240 V = Output power
26 W
Current
700 mA
220-240 V = Output power
28 W
Current
750 mA
220-240 V = Output power
30 W
Current
800 mA
220-240 V = Output power
30 W
Current
850 mA
220-240 V = Output power
30 W
Output voltage (min/max)
500 mA
27...40
550 mA
27...40
600 mA
27...40
650 mA
27...40
700 mA
27...40
750 mA
27...40
800 mA
27...37,5
850 mA
27...36
Product info
Country of production:
China
EAN:
8010703892798
HS code:
85044083

Documentation download

Approvals download
