STARLIGHT 60 200-1050 SUPERIOR IP67 (142138) - LED Drivers

back to LED Drivers

142138 - STARLIGHT 60 200-1050 SUPERIOR IP67

STARLIGHT 60 200-1050 SUPERIOR IP67 - 142138 - TCI

search engine powered by

Kubla

Features

Rated Voltage

220...240 V

Dimming:

D4i (Active DALI)

MIDNIGHT Function

ALO (Adjustable Light Output)

CLO (Constant Lumen Output)

DC EMERGENCY Function

Additional technical features:

RIPPLE FREE

ACTIVE PFC (pf>0.9)

NOT SELV (>120V)

DIMMING: AMPLITUDE (AM) IEEE1789-2015 - Dim-to-Warm

6/10 kV DM/CM SURGE Input Protection

Approvals:

ENEC

RCM

Plastic case:

Square

IP 20 (Independent Use)

IP 52

IP 54

IP 65

IP 66

IP 67

Size:

125 x 24 x 68 mm

last update:

2/27/2026

Constant Current

Current

NFC programming

Current

200 mA

220-240 V = Output power

23 W

Current

250 mA

220-240 V = Output power

28.75 W

Current

300 mA

220-240 V = Output power

34.5 W

Current

350 mA

220-240 V = Output power

40.25 W

Current

400 mA

220-240 V = Output power

46 W

Current

450 mA

220-240 V = Output power

51.75 W

Current

500 mA

220-240 V = Output power

57.5 W

Current

550 mA

220-240 V = Output power

60 W

Current

600 mA

220-240 V = Output power

60 W

Current

650 mA

220-240 V = Output power

60 W

Current

700 mA

220-240 V = Output power

60 W

Current

750 mA

220-240 V = Output power

60 W

Current

800 mA

220-240 V = Output power

60 W

Current

850 mA

220-240 V = Output power

60 W

Current

900 mA

220-240 V = Output power

60 W

Product info

Country of production:

Italy

EAN:

8010703895584

HS code:

85044083

Documentation download

Approvals download

Software

download
