142069 - SVM 110 700-2100 DALI NFC

SVM 110 700-2100 DALI NFC - 142069 - TCISVM 110 700-2100 DALI NFC - 142069 - TCI

Features

Rated Voltage
220...240 V
Dimming:
DALI-2 (also DALI-1)
PUSH (on the Mains)
ALO (Adjustable Light Output)
CLO (Constant Lumen Output)
Adjustable DC EMERGENCY
Additional technical features:
RIPPLE FREE
ACTIVE PFC (pf>0.9)
SELV <>
Approvals:
ENEC
RCM
Plastic case:
Slim
for Built-in
Size:
360 x 21 x 21 mm
last update:
7/13/2026
Constant Current
Current
NFC programming
Current
700 mA
220-240 V = Output power
37.8 W
Current
750 mA
220-240 V = Output power
40.5 W
Current
800 mA
220-240 V = Output power
43.2 W
Current
850 mA
220-240 V = Output power
46 W
Current
900 mA
220-240 V = Output power
48.6 W
Current
950 mA
220-240 V = Output power
51.3 W
Current
1000 mA
220-240 V = Output power
54 W
Current
1050 mA
220-240 V = Output power
56.7 W
Current
1200 mA
220-240 V = Output power
64.8 W
Current
1250 mA
220-240 V = Output power
67.5 W
Current
1350 mA
220-240 V = Output power
73 W
Current
1400 mA
220-240 V = Output power
75.6 W
Current
1450 mA
220-240 V = Output power
78.3 W
Current
1500 mA
220-240 V = Output power
81 W
Current
1600 mA
220-240 V = Output power
86.4 W
Current
1700 mA
220-240 V = Output power
91.8 W
Current
1800 mA
220-240 V = Output power
97.2 W
Current
1900 mA
220-240 V = Output power
102.6 W
Current
2100 mA
220-240 V = Output power
110 W
Output voltage (min/max)
700 mA
25...54
750 mA
25...54
800 mA
25...54
850 mA
25...54
900 mA
25...54
950 mA
25...54
1000 mA
25...54
1050 mA
25...54
1200 mA
25...54
1250 mA
25...54
1350 mA
25...54
1400 mA
25...54
1450 mA
25...54
1500 mA
25...54
1600 mA
25...54
1700 mA
25...54
1800 mA
25...54
1900 mA
25...54
2100 mA
25...54
Product info
Country of production:
Italy
EAN:
8010703475755
HS code:
85044083
