145138 - SIRIO SQ 110W/200-1000 AD

SIRIO SQ 110W/200-1000 AD - 145138 - TCI

search engine powered by

Kubla

Features

Rated Voltage

220...240 V

Constant Current

Current

NFC programming

Current

AOC via cables (ADJ. OUT. CURRENT)

Current

200 mA

220-240 V = Output power

44 W

Current

250 mA

220-240 V = Output power

55 W

Current

300 mA

220-240 V = Output power

66 W

Current

350 mA

220-240 V = Output power

77 W

Current

400 mA

220-240 V = Output power

88 W

Current

450 mA

220-240 V = Output power

99 W

Current

500 mA

220-240 V = Output power

110 W

Current

550 mA

220-240 V = Output power

110 W

Current

600 mA

220-240 V = Output power

110 W

Current

650 mA

220-240 V = Output power

110 W

Current

700 mA

220-240 V = Output power

110 W

Current

750 mA

220-240 V = Output power

110 W

Current

800 mA

220-240 V = Output power

110 W

Current

850 mA

220-240 V = Output power

110 W

Current

900 mA

220-240 V = Output power

110 W

Current

950 mA

220-240 V = Output power

110 W

Current

1000 mA

220-240 V = Output power

110 W

Current

1050 mA

220-240 V = Output power

110 W

Dimming:

D4i (Active DALI)

MIDNIGHT Function

CLO Function

DC EMERGENCY Function

Additional technical features:

RIPPLE FREE

ACTIVE PFC (pf>0.9)

NOT SELV (>120V)

DIMMING: AMPLITUDE (AM) IEEE1789-2015 - Dim-to-Warm

4/5 kV DM/CM SURGE Input Protection

4/8 kV DM/CM SURGE Input Protection

6/6 kV DM/CM SURGE Input Protection

6/8 kV DM/CM SURGE Input Protection

6/10 kV DM/CM SURGE Input Protection

Approvals:

ENEC

CCC

RCM

UKCA

Plastic case:

Square

for Built-in

Size:

150 x 40 x 90 mm

last update:

6/13/2024

Product info

Country of production:

Poland

EAN:

8010703893764

HS code:

85044083
