MP 50 K3 (122204) - Alimentatori LED

torna a Alimentatori LED

Caratteristiche

Tensione nominale
110...127 V
220...240 V
Corrente costante
Corrente
350 mA
220-240 V = Potenza in uscita
25 W
110-127 V =
25 W
Corrente
500 mA
220-240 V = Potenza in uscita
35 W
110-127 V =
35 W
Corrente
550 mA
220-240 V = Potenza in uscita
39 W
110-127 V =
39 W
Corrente
650 mA
220-240 V = Potenza in uscita
46 W
110-127 V =
40 W
Corrente
700 mA
220-240 V = Potenza in uscita
50 W
110-127 V =
40 W
Corrente
750 mA
220-240 V = Potenza in uscita
50 W
110-127 V =
40 W
Corrente
850 mA
220-240 V = Potenza in uscita
50 W
110-127 V =
40 W
Corrente
900 mA
220-240 V = Potenza in uscita
50 W
110-127 V =
40 W
Corrente
1050 mA
220-240 V = Potenza in uscita
50 W
110-127 V =
40 W
Regolazione:
NOT DIMMABLE
Altre caratteristiche tecniche:
RIPPLE FREE
ACTIVE PFC (pf>0.9)
SELV >60/<>
WIDE RANGE INPUT VOLTAGE
4/5 kV DM/CM SURGE Input Protection
12 V AUX. output
Omologazioni:
KEMAKEUR
ENEC
UL (other than class 2)
CCC
RCM
CE
EAC
UKCA
Involucro plastico:
Square
IP 20 (Independent Use)
ZHAGA AM3
Minimum cut-out hole diameter:
84 mm
Misure:
124 x 22 x 79 mm
ultimo aggiornamento:
11/03/2024
Output voltage (min/max)
350 mA
2...74
500 mA
2...72
550 mA
2...72
650 mA
2...72
700 mA
2...71
750 mA
2...66
850 mA
2...58
900 mA
2...55
1050 mA
2...48
